SLIDE GATE OPERATOR
RAM 100 AC
Residential & Light Commercial Slide Gate Operator
The RAM 100 AC is a reliable and durable slide gate operator designed for residential and light-commercial applications. Built for dependable performance and ease of use.
Available through Ramset’s Authorized Dealer Network.
We’re here to help you choose the right operator and answer any questions.
-
ETL Listed
Certified to UL 325
Our gate operators have been rigorously tested to meet the strict safety standards set forth by the UL 325 industry guidelines. To comply with these standards external entrapment protection devices will be required to meet UL 325 safety requirements. Your installer will recommend the appropriate types of devices based on your specific installation.
-
Emergency Foot Pedal Release
Ability to manually open you gate in case of an emergency.
-
Easy installation
EP Learn Mode: Created for the convenience of installers to easily install photoeyes.
Left Right Switch: Change the direction of the installation with the switch of a button
Close Delay: Adjustable timer, to meet the requirements of each unique installation
-
One Pass
Allows for gate to close immediately upon entrance.
-
Smart Home Compatible
Easily connect devices to the gate operator through the relay connection on the board.
| SPECS | Ram 100 AC |
|---|---|
| Class | Residential/ Commercial |
| Max Gate Weight | 1,000 lbs |
| Max Gate Length | 35' |
| Motor | 1/2 Hp, 115 VAC, 4.5 AMPS |
| Cycles | Continuous |
| Gate Speed | 12" per Second |
| VAC | 115- Single phase |
| Battery Backup System | - |
| W x L x H | 15" X 14.5" X 22" |
| Shipping Weight | 110 lbs |
| Emergency Release | Foot Pedal |
| RAM 100 AC | ||
|---|---|---|
| PART NUMBER | DESCRIPTION | QTY USED |
| 800-00-80 | Chassis, RAM 100 AC/DC | 1 |
| 800-02-03 | Gear Reducer - Size 43, Ratio 30:1 (C-Face) [R100] | 1 |
| 800-04-00 | Motor,C- Face, 120VAC, 1/2Hp | 1 |
| 800-06-22 | Sprocket - 41B14 1/2" [R100] AC/DC | 1 |
| 800-20-00 | Limit Switch [R100] | 2 |
| 800-20-20 | Limit Switch, Foot Pedal [R100, R1000,R5500] | 1 |
| 800-22-02 | Spring, FP Switch - 1/2' x 2' [R100,R1000,R5500] | 1 |
| 800-22-07 | Spring, Spring Loaded Bracket - Size 8- 1/2" [R100,R1000,R5500] | 2 |
| 800-24-22 | Fork, Foot Pedal Release [R100, R1000, R5500 AC/DC] | 1 |
| 800-52-27 | Chain, Limit - #41- 18Links [R100AC/DC] | 1 |
| 800-54-24 | Limit Switch Bracket [R100 AC/DC] | 1 |
| 800-54-75 | Bracket, Spring Loaded [R100] | 1 |
| 800-60-02 | Transformer, 115/230VAC TO 24VAC | 1 |
| 800-60-10 | Switch, Rocker | 1 |
| 800-64-50 | Radio Receiver Terminal | 1 |
| 800-65-01 | Control Board, Logic [AC/DC] | 1 |
| 800-65-02 | Control Board, Driver [AC] | 1 |
| 800-66-09 | Lexan, PLASTIC COVER [R100AC/DC] | 1 |
| 800-68-11 | Manual, RAM 100, RAM 1000, RAM 5500 AC | 1 |
| 800-70-22 | Horn Alarm Buzzer, 120 dB | 1 |
| 800-70-59 | Bearing Plate [R100] | 1 |
| 800-70-98 | Warning Sign For Gates - Slide/Swing | 2 |
| 800-75-07 | Cover, Polyethlene [R100] | 1 |
| 800-75-21 | Clutch Release Assembly | 1 |
| 800-58-51 | Clutch Release Assembly (Sprocket, 4 Pin Disc, Arbor, Snap Ring) | 1 |
| 800-22-06 | Spring - 1 1/4" X 1" (3 1/4 Turns) [R1000,5500] | 1 |
| 800-40-55 | Washer, Flat - Id 1 1/16" : Od 2" : Thickness .090" | 1 |
| 800-34-22 | Set Screw - 1/4" - 20 X 3/8" | 2 |
| 800-34-30 | Set Screw - 1/4' - 28 X 1/8'- *** Fine Thread *** | 1 |
| 800-42-32 | Key Way-1/4" X 2" Sq. | 1 |
| 800-40-05 | Wahser, Flat - Stainless Steel - Id 1/4", Od 1 1/2" | 1 |
| 800-32-56 | Screw, Machine - Zinc-Plated Steel Pan Head - 1/4"-20 X 1/2" | 1 |
| 800-75-30 | Idler Wheel Assembly- [R100] | 2 |
| 800-36-52 | Bolt, Hex Head - 5/8" - 11 X 3 1/2" | 1 |
| 800-38-18 | Nut, Hex Head - 5/8" | 2 |
| 800-73-70 | Idler Wheel, Uhmw - 2 1/2" X 1 1/4" - I.D. 5/8" [R100] | 1 |
| 800-75-72 | Limit Shaft Assembly- [R100] | 1 |
| 800-12-09 | Shaft, Limit Switch - 1/2" - 11 X 10.8" (6 3/8" Of Thread, 5/8" Thread Shaft) [R100] | 1 |
| 800-42-00 | Key Way - 1/8' Sq. X 7/8' | 1 |
| 800-20-50 | Limit Switch Nuts [R100] | 2 |
| 800-44-04 | Bearing, Sealed - 6202Rs X 1/2" [R100] | 2 |
| 800-70-10 | Collar, Limit Shaft - 1/2" [R100] | 2 |
| 800-75-65 | Chain Kit- [R100] | 1 |
| 800-38-16 | Nut, Hex Head - 1/2" | 4 |
| 800-52-02 | Chain - #41 (10ft per box) | 2 |
| 800-52-30 | Chain Bolt - 1/2" - 13 x 3 1/4" | 2 |
| 800-54-15 | Bracket, Chain (Left) - 3/8" x 2" x 2" x 3 1/4" | 1 |
| 800-54-16 | Bracket, Chain (Right) - 3/8" x 2" x 2" x 3 1/4" | 1 |
Installation & Support
Access manuals, specifications, installation videos, and technical support for your RAM 100AC.
Instruction Manual
Download the complete installation method.
Cut Sheet
View specifications and dimensions.
Installation Videos
Access our technician video library.
Technical Support
Contact our support team for assistance.
